SOLAR INVERTERS

We offer you the right device for each application:
for all module types, for grid-connection and feeding into stand-alone grids, for small

house systems and commercial systems in the Megawatt range.

SUNNY TRIPOWER CORE1

Stands on its own

• Topology: Transformerless
• Max. DC-voltage: 1000 V
• Max. apparent AC power: 50000 VA

SUNNY TRIPOWER 15000TL / 20000TL / 25000TL

The versatile specialist for large-scale commercial plants and solar power plants

• Topology: Transformerless
• Max. DC-voltage: 1000 V
• Max. apparent AC power: 15000VA / 20000 VA / 25000 VA

SUNNY TRIPOWER 5000TL - 12000TL

The Three-Phase Inverter – Not Only for Your Home...

• Topology: Transformerless
• Max. DC-voltage: 1000 V
• Max. apparent AC power: 5000 VA / 6000 VA / 7000 VA / 8000 VA / 9000 VA / 10000 VA / 12000 VA

SUNNY TRIPOWER 12000TL-US / 15000TL-US / 20000TL-US / 24000TL-US / 30000TL-US

More power. More flexibility. More profit.

• Topology: Transformerless
• Max. DC-voltage: 1000 V
• Max. AC-power: 12000 VA / 15000 VA / 20000 VA / 24000 VA / 30000 VA

SUNNY TRIPOWER 10000TLEE-JP

The innovative expert for low costs and high efficiency

• Topology: Transformerless
• Max. DC-voltage: 600 V
• Max. AC-power: 10000 VA

SUNNY TRIPOWER 25000TL-JP

The reliable specialist for decentralized systems on the medium-voltage grid

• Topology: Transformerless
• Max. DC-voltage: 1,000 V
• Max. apparent AC power: 25,000 VA

SUNNY TRIPOWER 24500TL-JP

The expert for decentralized systems in the Japanese low-voltage grid

• Topology: Transformerless
• Max. DC-voltage: 750 V
• Max. apparent AC power: 25,000 VA

SUNNY HIGHPOWER PEAK1

When maximum has no limit

SUNNY TRIPOWER 60

The efficient solution for tomorrow’s large-scale PV power plants

• Topology: Transformerless
• Max. input voltage: 1,000 V
• Max. apparent AC power: 60.000 VA

SUNNY TRIPOWER 60 JAPAN

The easy scalable solution for large PV systems

SUNNY BOY 3000TL / 3600TL / 4000TL / 5000TL
WITH REACTIVE POWER CONTROL

The same. Only better. The universal Sunny Boy.

• Topology: Transformerless
• Max. DC-voltage: 750 V
• Max. apparent AC power: 3000 VA / 3680 VA / 4000 VA / 5000 VA

SUNNY BOY 1.5 / 2.5

The new standard for small PV systems

• Topology: Transformerless
• Max. DC-voltage: 600 V
• Max. apparent AC power: 1500 VA / 2500 VA

SUNNY BOY 3.0 / 3.6 / 4.0 / 5.0

More than just an inverter. Smaller, simpler and more convenient with SMA Smart Connected.

SUNNY BOY 3.0-US / 3.8-US / 5.0-US / 6.0-US / 7.0-US / 7.7-US

Reduce costs across your entire residential business model

• Topology: Transformerless
• Max. DC voltage: 600 V
• Max. AC apparent power: See data sheet

SUNNY BOY 9000TL-US / 10000TL-US / 11000TL-US

High yield providers with UL listing

• Topology: Transformerless H5
• Max. input voltage: 600 V
• Max. apparent AC power: 9000 VA / 10000 VA / 11000 VA

SUNNY BOY 3500TL-JP / 4500TL-JP / 5400TL-JP

Perfection Plus. Usability.

• Topology: Transformerless
• Max. DC-voltage: 450 V
• Max. AC-power: 3500 VA / 4500 VA / 5400 VA
