Panianir’s New energy department

In order to develop DG power plants in Iran and to facilitate the privatization of this industry, this department has been vastly working in the field, aiming at reducing fossil fuel consumption, saving more energy, encouraging more use of free God-given energy resources in energy production and saving the environment as well. Panianir’s new energy department has been working in several areas containing design, equipment provision and implementation of PV power plants and small-scale generators, CHP and CCHP and advising in these areas in its specialized units.

1. Photovoltaic (PV) power plants

Panianir's photovoltaic department is working in three areas of a) on-grid residential and industrial small-scale plants, b) off- grid residential and industrial small-scale plants & c) large-scale power plants.

1.1. Panianir's services for large-scale power plants

1.1.1. The first phase: Pre-feasibility studies

1.1.1.1. Preparing feasibility study plan for solar power plant construction

To construct a solar power plant, Panianir manufacturing group attempts to conduct a study of the following factors in the first phase for dear investors:

• Evaluating several locations inside the country, regarding solar Atlas, to determine an appropriate spot to construct a solar power plant

• Calculating and estimating the amount of electric energy to be produced in a 1mw power plant for the climatic conditions of each location selected (regarded separately)

• Briefly evaluating any other factors effective in determining the final spot for power plant construction, comprising environmental issues, conditions of power transmission networks in the regarding district, its available networks and networks under construction, the power transmission company related to the power plant, social conditions, the effect of location selection on a development potential of power plant's customers and the potential of power plant development in future

• Preparing a basic design separately for each 1mw solar power plant, incorporating a determination of all technical specifications of the power plant's main components, an initial design of the equipment's electrical connection, mechanical structures, an estimation of the amount of civil operation for both options and other factors related in order to prepare LOM and to determine the project's initial schedule

• Preparing LOM based on the basic design for each power plant separately

• Estimating the costs of each solar power plant's construction and exploitation for a 5-year period and for the power plant's useful life

• Calculating an economic feasibility of each one of solar options considering the above-mentioned phases

This part of study is a pre-feasibility study of a renewable power plant (solar) construction project. In the second phase, the requirements demanded by Suna (Iran New Energy Organization) in order to complete the feasibility study report, as a prerequisite to the signing of the solar power plant construction's initial agreement, and to obtain the license for the solar (or wind) power plant must be incorporated. Such requirements are as follow:

1.1.1.2. An initial agreement of renewable power plant construction

Upon the agreement of the vice-minister in power and energy affairs, the applicants of the renewable (solar) power plant's license-in order to facilitate the document preparation needed for obtaining the construction license –may receive the initial agreement of solar power plant construction from power industry's privatization office after its qualification has been evaluated in the appraisal committee of civil applicant competencies and after determination of the power plant location and the issuing of feasibility study license.

• The validity period of this agreement is one year since the issuing date and may be extended up to 6 months upon the applicant request and Tavanir's confirmation. (Tavanir stands for Iran’s power production, transmission and distribution Co.)

• The work sheets and documents necessary for the issuing of the feasibility study are as follow:

• A work sheet of the project applicant's introduction (work sheet A)

• A work sheet of location introduction and the project's overall specifications (work sheet B)

• A work sheet of applicant competencies assessment(work sheet C)

Criteria to be considered in competing feasibility study report

1.1.1.3. Renewable (solar & wind) power plant construction license

The applicants of renewable power plant license may submit the request for the issuing of the power plant construction to Suna after their qualification has been evaluated in appraisal committee of civil applicant competencies, the construction location has been determined and the license for feasibility study has been issued. To do this, the applicants are required to prepare the following documents in advance:

• Documents representing license obtaining from related authorities for the use of land

• A environmental-related license from Environment Protection Organization

• A confirmation of the project of connection to power network

• A confirmation of the feasibility study plan in terms of the power plant's technical design and the amount of energy to be obtained

• The renewable power plant construction's license application form( it must be typed)

The responsibilities of a holder of renewable power plant construction license

Having prepared the essential documents, the applicants are expected to send the above-mentioned documents, together with the cover letter and the completed power plant construction application form, to Suna. Having evaluated the submitted documents, the authorities in Suna may submit their viewpoint to the privatization office in this regard. Afterwards, the construction license will be issued during a legitimate time period.

1.1.2. Feasibility study: preparing feasibility study for solar power plant implementation

The feasibility study report must incorporate the following issues in separate chapters:

1.1.2.1. Project description

The project, or the power plant to be constructed, must be described in terms of the following specifications from a technical perspective:

• Location: this includes an exact map of the location, all paths towards the location, the appropriate path for equipment transport, the power network and gas piping paths and the like and a topography of the land surrounding the location

• Power plant's technical specifications: this contains the equipment's technical specifications and those of selected processes, the equipment installation methods and their internal connection and the like

• Layout: this factor comprises the site plan of the power plant location representing the equipment installation method in the power plant, an estimate of the total land square and effective square of the power plant, a determination of water/electricity/gas/telephone splitting for the location at construction time

1.1.2.2. An estimate of the amount of electric energy produced annually

This includes evaluating the available data related to the location, evaluating energy resources, estimating the annual electric energy to be produced in the power plant and determining factors effective in equipment selection. Considering these, use of related software and typical and standard methods will help to guarantee the estimates and calculations.

1.1.2.3. Connection to the main power network

In this chapter, the connection to the power plant network and the mutual effects of the power plant and network are examined. Thus, in addition to the connection-to-network project, it is essential to conduct the following evaluations and calculations:

• Examining the available networks and those of being under construction in vicinity of the location intended for power plant construction ( including power substations & power transmission and distribution lines and top distribution network)

• Examining how to distribute electric load within power transmission substations and estimating the amount of load during power plant exploitation time

• Examining suggested options for network connection in technical terms and an economic comparison and prioritization of suggested plans

• Studying the transient stability of the power plant under study in conditions of maximum load and minimum load and at the time of short circuit on important network lines

• Studying short circuit in order to calculate the maximum level of short circuit on network substations' bus bars to select the degree of the power of switch on/off.

Considering Tavanir Co. or the district power distribution Co. as the certified authority to confirm the connection-to-network plan and to issue the related license, it is essential that all the studies be conducted under the supervision of , and based on the factors indicated by, the above-mentioned companies.

1.1.2.4. An environmental evaluation of the solar (or wind) power plant location

Here, the effects of power plants on the environment must be taken into account although renewable power plants are usually considered to be environmental-friendly.

1.1.2.5. Economic evaluation

After all the technical specifications the design plan of the power plant has been stated, applicants are expected to calculate their suggested project’s costs through typical, standard methods in engineering economics and to confirm the feasibility of the project in economic terms. Although the power costs purchased by power ministry from renewable power plants have been determined in advance and such cost may not undergo any changes, the projects with no economic justification will be totally inhibited. The economic analysis of the solar power plant construction must incorporate an examination and separation of investment costs, repair and maintenance, working capital, the annual income earned during the power plant’s useful life, the present value, the payback period and rate, etc.

1.1.2.6. Solar (wind) power plant’s implementation schedule

The project implementation schedule is provided at the end of the feasibility study report. This schedule may be cited in other phases, at the time of the issuing of the construction license and at the conclusion of the power purchase agreement, in particular. The starting time of the project will be the time when the power purchase agreement is concluded. The project timing will contain three periods as stated below:

• Initial period, comprising preliminary activities such as conclusion of the contractor agreements signed for equipment purchase or the project implementation, and determining how to maintain contract financing

• Power plant construction period, including operational measures up to the power plant initiation

• Exploitation period, containing all activities after the power plant initiation

The third phase may be started based on the employer decision, according to the study results and after the order given to Panianir manufacturing group. This phase incorporates stages of detail design and the power plant implementation, installation and initiation.

It is noted that Panianir manufacturing group, as the contractor during the exploitation stage, is capable of offering services to the employer.


Panianir's services for off-grid small-scale power plants include

• 1. Calculation and technical evaluation of the amount of load used

  2. The tracking and evaluation of construction location in an attempt to fine the best location

  3. Offering cheap, economical project packages

  4. Installation, testing and operation of projects

Panianir's services for on-grid small-scale power plants:

1. Evaluating the location in technical terms and offering consultation of the capacity of power plant construction in regarded location & of the investment amount

2. Doing follow-up procedures and establishing contracts with power transmission companies to sell the electricity produced

3. Designing the projects in accordance with standards approved by renewable energy organization and power transmission companies

4. Offering several economical packages to perform power plant construction

5. Offering consultation for how to receive power plant construction facilities

6. Installation, testing & operation of projects

2. Small-scale generators (SSG), CHP & CCHP

Distributed generation (DG) is an approach that employs small-scale technologies to produce electricity close to the end users of power. DGs are small-scale generators which may yield power in a maximum capacity of 25mw. Below are some DG types:

• Small-scale generators(SSG)

Internal combustion engines (ICE) are the most typical and most economical type of small-scale generators. These generators are of gas-fuel type and with regard to advances in related technology, they offer a high degree of efficiency and longevity. Moreover, they need a smaller place for installation and also a shorter time to be utilized.

• Combined Heat & Power(CHP) & Combined Cooling, Heat & Power (CCHP)

A strategy now used worldwide by energy-related policy makers as an effective tool in energy management is energy production based on a simultaneous production of cooling, power and heat (or cogeneration).

As a particular type of distributed generation, cogeneration may be defined as a simultaneous production of two or more energy forms (e.g. electricity, heat or cooling) from an initial simple source ( e.g. the chemical energy from different fuels).

1. Advising services

The applicants of building small-scale generators are required to complete a technical report and a financial report in order to receive needed licenses from the electricity company. Enjoying specialized experts and technical and Economics-related software, our company helps provide these reports. Having a long experience in cooperating with several electricity companies and in providing authorized technical and financial reports and helping them approved in appraisal committees and participation committees, the company announces its readiness for preparation, submission and approval of technical and financial reports in related departments.

• Providing technical consultation

• Preparing a feasibility study

• Obtaining technical confirmations from DG development center

• Producing designs and obtaining licenses needed for connection to the network

• Signing guaranteed purchase agreement with Tavanir Co.

• Obtaining certificates needed for power plant installation

• Obtaining confirmations from gas Co.

2. Construction and exploitation services

Relying on its long experience in construction and exploitation of small-scale generators and having carried out technical evaluations and needs assessment, Panianir group is well capable of constructing and exploiting these generators in accordance with customer demands. Panianir group will be held liable for performing all needed measures from zero phase stage up until the generators exploitation and connection to the universal network or to that of the applicants.

Activities in area of clean energy sources are as follow:

• Location evaluation and needs assessment

• Obtaining needed confirmations and licenses

• Construction and exploitation

3. Embracing participation projects

Panianir manufacturing group may eagerly welcome all participation projects in construction of SSGs and DGs and announce its readiness for construction of SSGs in cooperation with applicants in the field.

4. SSG Sale

Relying on its fine cooperation with manufacturers and sellers of small-scale generators (SSG), Panianir group is ready to offer any services concerning the sales of gas-fuel generators.
